NOTE: The item need connect with the Access Point Router together, then it can work, and the Access Point Router is NOT included.

Product Description

* Low-noise receive gain.
* Signal activity LED indicates.
* High Gain, High Value, High Performance.
* Maximum output power of 8000mW by the Booster.
* Plug-and-play, Easy installation, no driver needed.
* Ideal for increase the 2400-2500 MHz frequency devices.
* Increase the effective range and coverage area of your Wi-Fi network.
* Simply attach the booster in between the standard antenna on a wireless router or wireless access point and watch your range grow.
* The amplified wireless signal may even penetrate complex environments with many walls and obstacles.
* Ideal for use with 2.4GHz Wireless LANs, Support 802.11b, 802.11g, 802.11n (2.4Ghz mode only).

Features

* Recommend the input power of RFIN port to between 7dBm and 15dBm.
* Make sure all power supply to the booster and the AP/Router unit be disconnected before removing or changing antenna.
* When finishing connecting the booster and the AP/Router, restore power supply first to the booster and then to AP/Router subsequently.
* Waterproof, lightning protection equipment should be attached to outdoor antenna.
* Keep away from heat and keep ventilated.
* Please comply with local regulations of electromagnetic radiation.

Specifications

Operation Range: 2400-2500 MHz
Operation Mode: Bi-directional, half-duplex, Auto-Switching via carrier sensing.
Frequency Response: ± 1dB over operation range
Input Power: 3dBm (Min.)-20dBm (Max.)
Input Power: 5 ~ 20 dBm
Optimal Input Power: 9 ~ 15 dBm
Output Power: 8000mW/39dBm nominal for 802.11b/11Mbps
Connector: SMA Receptacle, 50ohm
Transmit Gain: 17dBm nominal
Receiver Gain: 11dBm.
Receive Noise Figure: 3.0dBm nominal
Operating Temperature: -40 to 70 degree
Operating Humidity: Up to 95% relative humidity
Material: Cast Aluminum
